Backup Transfers
1GbE Connection (Gigabit-H3X)
The maximum number of real-time transfers through one 1GbE port of the H3X board on
an XT3 server in 1080i, without SLSM REC, are summarized in the following table:
Codec
Field
Rate
Video
Bitrate
(Mbps)
Block-
Based
Bandwidth
(MB/s)
RT
Transfers
Transfer
Speed
(faster than
RT)
XDCAM HD 50.00 Hz 50 6.5 10.7 9.9x
Apple ProRes
422 LT
50.00 Hz 85 11.4 6.1 5.7x
HD Mjpeg
Standard
50.00 Hz 100 33.3 2.1 1.9x
HD Mpeg-2 Intra 50.00 Hz 100 33.3 2.1 1.9x
DVCPro HD 50.00 Hz 100 12.9 5.4 5.1x
AVC Intra 100 50.00 Hz 111 13.3 5.2 4.8x
Avid DNxHD®
120
50.00 Hz 120 14.8 4.7 4.4x
Apple ProRes
422 SQ
50.00 Hz 120 16.6 4.2 3.9x
Avid DNxHD®
185
50.00 Hz 185 22.2 3.1 2.9x
Apple ProRes
422 HQ
50.00 Hz 185 25.0 2.8 2.6x
