EVS XT Series User Manual

XT Series DISK RECORDER - Version 10.01 - Software Technical Reference Manual Issue
10.01.D
EVS Broadcast Equipment SA
–
October 2009
7
This window is used to define video & audio channels, type and configuration of
recorders, audio format and audio-video synchronization parameter. All the
parameters are described in this section.
1.3.2 HOW TO MODIFY A/V CHANNEL PARAMETERS
1. From the EVS main menu, press F9 to open the Maintenance menu.
2. Select the ‘Channel Parameters’ item and press ENTER.
3. Select the Application to configure and press ENTER.
The Audio Video Channel Parameters window appears.
4. Use the <TAB> key to move from one box to the next one. Some information
about the current parameter is displayed in the INFO area.
5. Press <TAB> or the arrow keys (←,→, ↑,↓ ) to move across the different
parameters in the window.
6. When the desired field is selected, modify the parameter to its new value with
<SPACE BAR> or by entering its numeric value and then press ENTER to
validate.
7. Press F3 to enter the Advanced Parameters.
8. Press F4 to save the current configuration. A dialog Box appears to enter a
name.
9. Press F5 to load the list of configurations previously saved.
10. Press ALT + Q to exit the A/V Channel parameters window.
OR:
1. From the ‘Application List’ in the EVS main menu, select the application to
configure and press F8.
2. Continue from step 4.
1.3.3 AUDIO & VIDEO PARAMETERS OVERVIEW
Note:
When Modifying the value of a parameter in the Audio & Video Channel
Parameters, always press ENTER after changing the value of a parameter
to validate the new choice. Check the channels table in the centre of the
screen to make sure that the changes are reflected there.
LOCK VIDEO CONFIGURATION
Possible values: Yes / No
This item enables/disables the access to the modifications of the next three items:
Video Players, Video Recorders and Type for REC1.
The video configuration is locked if Option Code 4 (Authorize video configuration
changes) is not active in the Options List.
