EVS XT Series User Manual

Issue
10.01.D
XT Series DISK RECORDER
–
Version 10.01 - Software Technical Reference
EVS Broadcast Equipment SA
–
October 2009
10
AUDIO FORMAT
Possible values: [Analog (A), AES/EBU (D), Embedded (E), Dolby E AES (DY),
Dolby E Embedded (EY)]
This parameter allows selecting the Audio format.
When the Audio Format is set to AES/EBU (D or DY) or Embedded (E or EY), the
analogue audio outputs (if installed on the server) are automatically activated and
can be used for additional monitoring.
When the Audio Format is set to Embedded (E or EY), the digital audio (AES/EBU)
outputs (if installed on the server) are also active.
For more information on Dolby Audio Management, refer to section1.3.5 ‘Dolby
Au
dio Management’, on page 15.
AUDIO TYPE
Possible values: [1 Track, 2 Tracks, 4 Tracks, 8 Tracks, 16 Tracks]
This parameter allows selecting the type of audio (number of mono audio tracks
associated to each video channel).
The following table specifies the audio types available for the various audio
formats:
Audio
Type
Analog (A) Digital
(D - DY)
Embedded
(E - EY)
1 track X
2 tracks X X
4 tracks X X X
8 tracks X X
16 tracks X
LIPSYNC
Range for PAL: From -41,458 ms to 14,708 ms Î 848 à 3544 (samples)
0 ms Î 2838
Range for NTSC: from -34,625 to 12,125 ms Î 688 à 2932 (samples)
0 ms Î 2350
The Lipsync parameter is the delay (in ms) between video and audio signals. A
positive value means video is ahead of audio. A negative value means audio
ahead of video.
This parameter is also available from the Setup menu of the Remote when the
Multicam application is started. Changing the Lipsync value in the Setup menu will
update it in the EVS menu and vice versa.
CTRL-↑/↓ changes the value per 1 msec step. The operator can also enter directly
a value with the keyboard.
