4. Software Specifications
4.1. Video Specifications
Video Standards
The following table lists the video specifications in HD and UHD-4K formats for your
XT4K server.
High Definition UHD-4K
Video Formats 720p 50/59.94fps
1080i 50/59.94fps
1080p 50/59.94fps (3G)
UHDTV-4K 50/59.94fps
Digital Interface 10-bit 4:2:2 Serial (ST 292-
1:2011).
Full frame synchronizer at
input.
10-bit 4:2:2 Serial (ST 292-
1:2011).
Full frame synchronizer at
input.
Number of Channels 2, 4, 6, 8, 10 or 12 channels,
reversible REC/PLAY
2 or 4 channels, reversible
REC/PLAY
Monitoring & Down-
converters
1 SDI or IP output per
channel, with OSD
1-built in down-converter per
channel.
1 3G-SDI or IP output per
channel with OSD.
Reference Analog Black Burst and HD
Tri-Level Sync
HD Tri-Level Sync
The extended configurations, including 10 or 12 channels, are available with the 10-
Channel configurations license code (36), Channels Max license code (34)and are
described in the Configuration manual, Supported Configurations chapter.
