6.3. V4X Video and Reference Boards
6.3.1. Description
Overview
The V4X board is divided in several parts:
• a base board identified as V4X base
• four modules identified as V4X A, B, C and D
WARNING
It is highly advised not to remove a V4X board from your EVS server. Should
you have to do so, manipulate the board very carefully, making sure it is not
exposed to mechanical or electric shocks.
COD Modules
V4X modules are the actual codec modules, each of them being able to be configured by
software either as an encoder (for a record channel) or as a decoder (for a play channel).
They support the following features:
• UHD-4K on a single V4X module
• 720p / 1080i / 1080p 50/59.94Hz video standards
