3. Hardware Specifications
3.1. Mechanical Dimensions and Weights
3.1.1. Rack Mount 6U Main Frame
Weight
Disk Configuration Weight
6U - 19 inches chassis with 12 HDD on hot swap rack 39 kg / 86.0 lb
Dimensions
The following drawings provide the various dimensions, in mm, of the XT4K server with a
6U chassis.
Front view
Left view
