SMPTE Standards
The following table lists the SMPTE standards supported by your server.
Configuration SMPTE standard
HD SDI ST 292-1:2011, ST 292:2012
(720p 50 and 59.94Hz; 1080i 50 and
59.94Hz)
Embedded audio HD ST 299-0:2010, ST 299-1:2009
AES/EBU audio ST 272:2004
LTC ST 12-1:2008, ST12-2:2008
D-VITC ST 266:2012
Ancillary TC in HD RP 188
Vertical Ancillary Data ST 334:2000
VC-3 ST 2019-1:2008
Mapping of Audio Metadata into
Vertical Ancillary data
ST 2020-2:2008, ST 2020-3:2008
3G SDI ST 424:2006
3G SDI – Data mapping ST 425-B:2008
Image Format and Ancillary Data
Mapping for the Quad Link 3 Gb/s
Serial Interface
ST 425-5:2014
12G-SDI Bit-Serial Interfaces ST 2082
Transport of High Bit Rate Media
Signals over IP Networks
ST 2022-6:2012
4.2. Audio Specifications
General Specifications
See section "Audio Channels" on page 39 for an overview on the possible audio hardware
configurations.
• 4 additional analog balanced output channels for monitoring
• All audio connectors on mainframe
• The Lo-Res audio is Mpeg-1 Layer II at 48 kHz sampling frequency.
• The MADI interface supports 64 synchronous audio tracks @ 48KHz.
