Maximum Number of Embedded or MADI Audio Channels
The 6U servers provide the following maximum number of embedded or MADI audio
channels per video channel with intra codecs:
Configuration Mode Embedded MADI
2-channel configurations 2*16 audio mono
(= 32 tracks)
2*16 audio mono
(= 32 tracks)
4-channel configurations 4*16 audio mono
(= 64 tracks)
4*16 audio mono
(= 64 tracks)
6-channel configurations 6*16 audio mono
(= 96 tracks)
6*16 audio mono
(= 96 tracks)
8-channel configurations 8*16 audio mono
(= 128 tracks)
8*16 audio mono
(= 128 tracks)
10-channel configurations 10*16 mono
(=160 tracks)
10*16 mono
(=160 tracks)
ChannelMax
configurations
12*16 mono
(=192 tracks)
12*16 mono
(=192 tracks)
Audio Processing
• Uncompressed audio
• 24 bit processing and storage
• Sample rate converter from 25-55 kHz to 48kHz
• Audio scrub
• Audio mix
