The data is available for:
• one 1GbE and 10 GbE port of the GbE board
• field rates of 50.00Hz (PAL) and 59.94Hz (NTSC)
1GbE Connection (PAL)
Codec
Video Bitrate
(Mbps)
Block-Based
Bandwidth (MB/s)
Transfer Speed
(faster than RT)
Apple ProRes 422 LT 85 11.7 7.6x
AVC-Intra 100 111 14.8 6.0x
XAVC-Intra HD 111 14.8 6.0x
Avid DNxHD® 120 120 16.6 5.4x
Apple ProRes 422 SQ 120 16.6 5.4x
Avid DNxHD® 185 185 25.0 3.6x
Apple ProRes 422 HQ 185 25.0 3.6x
XAVC-Intra 4K 500 66.6 1.3x
1GbE Connection (NTSC)
Codec
Video Bitrate
(Mbps)
Block-Based
Bandwidth (MB/s)
Transfer Speed
(faster than RT)
Apple ProRes 422 LT 100 14.1 6.4x
AVC-Intra 100 111 14.5 6.2x
XAVC-Intra HD 111 14.5 6.2x
Avid DNxHD® 145 145 20.8 4.3x
Apple ProRes 422 SQ 145 19.2 4.7x
Avid DNxHD® 220 220 30.0 3.0x
Apple ProRes 422 HQ 220 30.0 3.0x
XAVC-Intra 4K 600 68.5 1.3x
