Connectors
The following table lists the connectors and their respective function:
Connector Function
A Rear panel connection for codec 1
B Rear panel connection for codec 2
C Rear panel connection for codec 3
D Rear panel connection for codec 4
M Rear panel connection for monitoring
H Link to H3XP-S board
X For internal use
LEDs
The table below lists the LEDs available with the genlock functionality.
WARNING
It is crucial to have a continuous and stable genlock signal when the server is in
operation. In case of interferences on the genlock signal that would cause parity
violations, the recorders will automatically be restarted to maintain data
integrity.
LED Color Status Function
GLK — Off The genlock module is not initialized.
Green Blinking The genlock module is properly initialized, but no valid
genlock signal is detected.
On The module is initialized and a valid genlock signal is
detected.
Red Blinking There is a genlock problem.
On A resync is needed.
