5.10 Remote control
Damage due to the use of non-genuine parts!
The manufacturer's warranty becomes void if non-genuine parts are used!
• Only use system components and options (power sources, welding torches, electrode
holders, remote controls, spare parts and replacement parts, etc.) from our range of
products!
• Only insert and lock accessory components into the relevant connection socket when the
machine is switched off.
The remote controls are operated on the 19-pole remote control connection socket
(analogue).
Please note the relevant documentation of the accessory components.
The operation of the remote control and its settings are directly dependent on the configuration of the
respective welding machine or wire feed unit. The settings are defined by changeover switches or by
setting special parameters (dependent on the control).
Infinite adjustment of the operating point (wire speed/welding voltage).
• Switch remote control ON/OFF changeover switch to the ON position.
• Switch machine operation changeover switch (operating point) to
(see corresponding documentation).
