USE AND MAINTENANCE MANUALUSE AND MAINTENANCE MANUAL
Chain hoist from 198kg to 2500kg
KEY NUMBERKEY NUMBER DESCRIPTIONDESCRIPTION A4I ITA CODE / NOTEA4I ITA CODE / NOTE
MF-101
Medium Frame Black Cover with Handle 215x160x139mm
(without screws)
LT XRS-0079
MF-102
Medium Frame KIT Cover Handle 42x430mm – Ø11.75 with:
n.2 Screw TSPEI M6x25 10.9 ZB
n.2 Self-locking Nut High M6
n.2 Bush Øe18 - Øi6 - L=11mm
LT XRS-0136
MF-103 Medium Frame Cover Gasket Ø3mm – L=650mm (n.1 x Cover) LT XRS-0138
MF-104
Medium Frame Chain Bag Steel Bracket with:
n.4 Screw UNI 7380 6x16mm TBEI 10.9 ZB
LT XRS-0080
MF-105 Medium Frame Load Wheel Housing Not available as spare
MF-001 Screws UNI 5931 6x40mm TCEI 8.8 ZB (n.4 x cover) 3.0740
MF-901 (for DC/LVC Hoist) Black Spiral Cable Gland PG13.5 for Cable 4G1,5mmq LT XRS-0038
MF-902 (for DC/LVC Hoist) Power Cable 4G1.5mmq LT AXCAVNE4G1.5
MF-903 (for DC/LVC Hoist) Shark Plug CEE 400VAC 16A 6h 3P+T IP67 LT AXPCE0142-6X
MF-904
(for DC Hoist) Closed hole with plug Black Stop Plug PG 13.5.
Control Cable not provided.
(for LVC Hoist) Black Spiral Cable Gland PG13.5 for Cable 4G1,5mmq
LT AXCEM1052013N
LT XRS-0038
MF-905
(for DC Hoist) Control Cable not provided
(for LVC Hoist) Control Cable 4G1.5mmq
Not provided
LT AXCAVNE4G1.5
MF-906
(for DC Hoist) Control Cable not provided
(for LVC Hoist) Shark Socket CEE 230VAC 16A 9h 3P+T IP67
Not provided
LT AXPCE2142-9X
MF-501 Galvanized Steel Chain 6x18mm RTS DAT (1m) LT XRC0618-01M
MF-502 Phosphated Black Steel Chain 6x18mm RTS DAT (1m) LT XRC0618K-01M
MF-503 Medium Frame Chain End Stop Block 6x18mm LT XRSFC618
MF-504
Medium Frame KIT Swivel Chain Hook (Bush M14 + Hex Socket) with:
n.1 Chain Hook 1.25t-SF 4:1 (Bush M14 + Hex Socket) – (LT XRS-0183)
n.1 Chain Hook Block 1 reeve
n.1 Lock Pin
n.1 Elastic Pin – (LT XRS-0097)
LT XRSGGCW1250E
MF-505
Medium Frame KIT Swivel Body Hook (Bush M14 + Hex Socket) with:
n.1 Body Hook 1.25t-SF 4:1(Bush M14 + Hex Socket) + plate
n.2 Screw UNI 5739 M16x30 TE 8.8 ZB
LT XRSGGW1250D
To Next Page
