USE AND MAINTENANCE MANUALUSE AND MAINTENANCE MANUAL
Chain hoist from 198kg to 2500kg
KEY NUMBERKEY NUMBER DESCRIPTIONDESCRIPTION A4I ITA CODEA4I ITA CODE
LF-101 Large Frame High Black Cover with Handle 265x178x110mm (no screws) LT XRS-0081
LF-001 Screws UNI 5931 5x30mm TCEI 8.8 ZB (n.4 x cover) LT 999
LF-102
Large Frame KIT Cover Handle 42x475mm – Ø11.75 with:
n.2 Screw TSPEI M6x25 10.9 ZB
n.2 Self-locking Nut High M6
n.2 Bush Øe18 - Øi6 - L=11mm
LT XRS-0058
LF-103
Large Frame Tubular Gasket Ø2.5mm – L=750mm
(n.1 x Cover + n.1 x Motor Housing)
LT XRS-0078
LF-104
Large Frame Chain Bag Steel Bracket with
n.2 Screw 5931 8x30mm TCEI 8.8 ZB
n.2 Washers M8
n.1 Screw 5931 6x100mm TCEI 8.8 ZB
n.1 M6 Selflocking Nut
LT XRS-0005
LF-105 Large Frame Brake Frame
Not available separately
(LF-113)
LF-002 Screws UNI 5931 6X40mm TCEI 8.8 ZB (n.4 x frame) 3.0740
LF-106 Large Frame Gearbox Housing Gasket LT XRS-0075
LF-107 Large Frame Gearbox Housing LT XRS-0140
LF-004 Metal Pin 6x16mm (4 per Gearbox Housing – 2 per side) LT 999
LF-108 Large Frame Loadwheel Housing Gasket LT XRS-0077
LF-109 Large Frame Loadwheel-Electric Motor Frame LT XRS-0141
LF-003
Screws UNI 5931 6X30mm TCEI 8.8 ZB
Screws UNI 5931 6X35mm TCEI 8.8 ZB
Screws UNI 5931 6X45mm TCEI 8.8 ZB (n.2 x frame)
3.7790
3.0800
3.7784
LF-110
Large Frame Motor Housing with:
n.1 PG16 and M16x1.5 cap
n4 Screws UNI 5931 6X75mm TCEI 8.8 ZB
LT XRS-0067
LF-111
Large Frame Low Black Cover with Handle 265x178x59mm
(no screws)
LT XRS-0025
LF-112 Large Frame Aluminium Turnbuckle with n.2 screws LT XRS-0069
LF-113
Large Frame KIT Brake Frame with:
n.1 brake frame
n.1 tubular gasket (LT XRS-0078)
n.1 loadwheel housing gasket (LT XRS-0075)
n.2 bearing 6005 + 6205
LT XRS-0110
LF-901 (for DC/LVC Hoist) Black Spiral Cable Gland PG16 for Cable 4G2,5mmq LT XRS-0057
LF-902 (for DC/LVC Hoist) Power Cable 4G2.5mmq LT AXCAVNE4G2.5
LF-903 (for DC/LVC Hoist) Shark Plug CEE 400VAC 16A 6h 3P+T IP67 LT AXPCE0142-6X
LF-904
(for DC Hoist) Closed hole with plug Black Stop Plug PG16.
Control Cable not provided.
(for LVC Hoist) Black Spiral Cable Gland PG16 for Cable 4G2,5mmq
LT AXCEM1052016N
LT XRS-0057
LF-905
(for DC Hoist) Control Cable not provided
(for LVC Hoist) Control Cable 4G2.5mmq
Not provided
LT AXCAVNE4G2.5
LF-906
(for DC Hoist) Control Cable not provided
(for LVC Hoist) Shark Socket CEE 230VAC 16A 9h 3P+T IP67
Not provided
LT AXPCE2142-9X
LF-501 Galvanized Steel Chain 8x24mm RTS DAT (1m) LT XRC0824-01M
LF-502 Phosphated Black Steel Chain 8x24mm RTS DAT (1m) LT XRC0824K-01M
LF2-504 Large Frame Double Reeves KIT Swivel Chain Hook (5.4t-SF 4:1) LT XRSGGCW5400A
LF2-505 Large Frame Double Reeves KIT Swivel Body Hook (5.4t-SF 4:1) LT XRSGGW5400A
LF2-506 Large Frame Dead and Block 8x24mm LT XRS-0119
