USE AND MAINTENANCE MANUALUSE AND MAINTENANCE MANUAL
Chain hoist from 198kg to 2500kg
LF2 - Gear Box Exploded DrawingLF2 - Gear Box Exploded Drawing
WARNINGWARNING
For more information contact EXE Technology OfficeFor more information contact EXE Technology Office
LF2 - Motor Side Exploded DrawingLF2 - Motor Side Exploded Drawing
WARNINGWARNING
For more information contact EXE Technology OfficeFor more information contact EXE Technology Office
LF2 - Load Wheel & Chain Guide Exploded drawingLF2 - Load Wheel & Chain Guide Exploded drawing
KEY NUMBERKEY NUMBER DESCRIPTIONDESCRIPTION A4I ITA CODEA4I ITA CODE
LF-401 Large Frame Load Wheel 5 pocket for 8x24mm chain + shaft & gear LT XRS-0125
LF-402
Large Frame KIT Internal Chain Guide for 8x24mm chain (2 pcs) with n.2
cylindrical fixing pins and ½ moon inserter
LT XRS-0147
LF-403
Large Frame PVC External Chain Guide Plate for 8x24mm chain with n.4
screws 5x30mm TSPI+ ZB
LT XRS-0061
LF-501 Galvanized Steel Chain 8x24mm RTS DAT (1m) LT XRC0824-01M
LF-502 Phosphated Black Steel Chain 8x24mm RTS DAT (1m) LT XRC0824K-01M
LF2 - Electrical components Exploded DrawingLF2 - Electrical components Exploded Drawing
WARNINGWARNING
For more information contact EXE Technology OfficeFor more information contact EXE Technology Office
