Introducing the EXFO EX1
4 EXFO EX1
EXFO EX1 Device
On/Off Switch and LED
Turns the EXFO EX1 device on or off.
To turn the EXFO EX1 device on, press and hold the on/off switch
(about 1 second) until the LED starts flashing.
To turn the EXFO EX1 device off, press and hold the on/off switch
(about 5 seconds) until the LED starts flashing, then the LED turns off.
The power LED reports the EXFO EX1 device status as follows:
IMPORTANT
The EXFO EX1 device automatically shuts down after 3 minutes (by
default) of inactivity when the EXFO EX1 device is not charging
using the provided USB power adapter. Refer to Power Saving on
page 41 for more information.
LED State Description
Off EXFO EX1 device is turned off.
Green EXFO EX1 device is turned on and ready to be used.
Green flashing fast EXFO EX1 device is booting or shutting down.
Amber flashing EXFO EX1 device is performing a firmware update.
Red EXFO EX1 device failed to boot.
