Speedtest Settings
38 EXFO EX1
System
The list of access points are color coded allowing their
identification on the graph. Each access point (SSID) is listed with
its SSID, BSSID, vendor name, channel number, frequency (in
parenthesis), and signal strength. If the connected Wi-Fi access
point is part of the list, it appears as the first access point in the list
with the icon
to its left.
Tap on an access point to highlight it on the graph. Tap again on the
access point to un-select it. It is possible to highlight more access
points by tapping on each access point.
Wi-Fi Access Points allow the EXFO EX1 device to connect to a Wi-Fi
access point for testing, or downloading and installing new firmware
update (see Device Information on page 41).
For a secured access point enter the password and tap CONNECT.
Show Password check box when selected displays the password.
Show Advanced check box when selected displays the access
point DHCP and security information.
Tapping on the Connected Wi-Fi access point displays the following
information:
Wi-Fi Details
BSSID: Basic Set Identifier
Vendor: Manufacturer name
Frequency Band: 2.5 GHz or 5 GHz
Channel: Actual number associated to a channel: 1 to 14 for
2.5 GHz; 1 to 200 for 5 GHz.
