Speedtest Settings
EXFO EX1 39
System
 Signal Strength: The received signal strength of the Beacon frame
in dBm.
 Link Speed: Link speed value of the connected Wi-Fi network in
Mbit/s.
 Security: The Wi-Fi interface security mode.
Network: The connected Wi-Fi network information: IP Address,
Subnet Mask, Gateway, DNS 1, DNS 2.
CANCEL and FORGET allows respectively to close the pop-up or
disconnect from this Wi-Fi access point.
Signal
Strength
Signal strength value in
Percentage dBm
Excellent 100 % > -50 dBm
Good 80 % to 100 % -50 dBm to -60 dBm
Fair 60 % to 80 % < -60 dBm to -70 dBm
Weak 40 % to 60 % < -70 dBm to -80 dBm
Security Mode Description
Unsecured Security is disabled.
WPA2 - Personal Wi-Fi Protected Access Personal Version 2
WPA2 - Enterprise Wi-Fi Protected Access Enterprise Version 2
WEP Wired Equivalent Privacy
WPA Wi-Fi Protected Access
