Setting Up Your Unit

132 FTB-2/FTB-2 Pro and FTB-4 Pro

Setting ToolBox X Behavior

You can specify how ToolBox X behaves when the application is started,

minimized or closed.

To set the ToolBox X behavior:

1. From the main window, tap the System Settings button.

2. Tap ToolBox X Setup.
