Introducing the Optical Switch
4 Optical Switch
Available Models
Below are a few examples of the available models:
Note: Actual connectors may differ from those depicted in the illustrations.
Common port
1 x 2 FTBx Optical Switch Module
Switch ports 1 and 2
Common port
1 x 8 FTBx Optical Switch Module
Switch ports 1 to 8
