Introducing the Optical Switch
10 Optical Switch
Correspondence Between Port Numbers and Fiber Numbers (RTUe-9120)
Correspondence Between Port Numbers and
Fiber Numbers (RTUe-9120)
The table below lists the fiber numbers associated with each port for easier
identification.
Note: The number of ports varies with the model of switch that you have
purchased.
Port Number Fiber Numbers
11 to 16
2 17 to 32
3 33 to 48
4 49 to 64
5 65 to 80
6 81 to 96
7 97 to 112
8 113 to 128
9 129 to 144
10 145 to 160
11 161 to 176
12 177 to 192
13 193 to 208
14 209 to 224
15 225 to 240
16 241 to 256
