Introducing the Optical Switch
Optical Switch 9
Available Models
LED Switch ports
Common port
RTUe-9120 switch - Front 16 ports
Grounding lug
USB port (type B) to connect the switch to a compatible EXFO platform
RTUe-9120 switch - Back
Screw holes for grounding lug
(alternative grounding method)
