Introducing the Optical Switch
Optical Switch 17
Typical Applications
3. Using the same test jumpers, connect the light source to one of the
switch ports, and connect the switch common port to the power meter
detector port (the Optical Switch now replaces the bulkhead
connector).
4. The IL registered on the power meter will then be the switch port IL
including connectors.
