Exmark Quest Lawn Mower - Torque Requirements; Product Overview; Component Identification; Tread Width and Wheel Base

ProductOverview
TreadWidth:(CentertoCenterof
Tires,Widthwise)
48inchDeck52inchDeck
DriveWheels36.0inches
(91cm)
36.8inches
(93cm)
CasterWheels33.5inches
(85cm)
33.5inches
(85cm)
WheelBase:(CenterofCasterTireto
CenterofDriveTire)
48inchDeck52inchDeck
48.9inches(124cm)48.9inches(124cm)
CurbWeight:
48inchDeck52inchDeck
645lb(293kg)660lb(299kg)
TorqueRequirements
BoltLocation
Torque
SpindlePulleyNut95-105ft-lb(129-142N-m)
BladeMountingBolt
(lubricatewithanti-seize)
32-42ft-lb(43-57N-m)
EngineMountingBolts
27-33ft-lb(37-45N-m)
Anti-ScalpRollerNyloc
Nut
27-33ft-lb(37-45N-m)
WheelLugNuts
70-90ft-lb(95-122N-m)
ClutchMountingBolt
(securedwiththreadlocker)
50-55ft-lb(68-75N-m)
SparkPlug
15ft-lb(20N-m)
ProductOverview
Figure3
1.Frontcasterwheel8.Engine
2.Anti-scalproller
9.Seat
3.Heightofcutfootlever
10.Armrest
4.Dischargedeector
11.Motioncontrollevers
5.Heightofcutadjustment
12.Parkbrake
6.Reardrivewheel13.Footrest
7.Controlpanel14.Washouttting
