Explorer FX15 - Page 52

FX15 Controller Technical Bulletin
52
Table 12: User Interface Displays
Ordering Codes Description
LP-DIS65P10-0C
Large User Interface V.2, (4x20 character) LCD backlit
display (LUI with std JCI front plate)
LP-DIS60P10-0C
Medium User Interface V.2, (4 x20 character) LCD backlit
display, panel mount version
LP-DIS60P11-0C
Medium User Interface V.2, (4 x20 character) LCD backlit
display, wall mount isolated version
LP-DIS60U10-C
Integrated MUI, (4 x 20) LCD backlit display for FX15
Table 13: Accessories
Ordering Codes Description
LP-KIT007-000C
Link cable for the connection of the FX15 to the MUI/LUI
display -3m (19 ft)
LP-KIT015-000C
Kit of female screw connectors
LP-KIT015-001C
Kit of female cage clamp connectors
LP-KIT100-000C
FX Programming Key
DT-9100-8901
Power Supply for Programming Key and LUI: 230 VAC/12
VDC
LP-KIT100-001C
Power Supply for Programming Key and LUI: 230 VAC/12
VDC
Table 14: Room Command Modules Available Only in Europe
Ordering Codes Description
LP-TR23024-10VA
Transformer for FX05, 10 VA
LP-KIT006-000C
Room Sensor module for FX05 +/- dial, occupancy button,
fan speed, service port
LP-KIT006-001C
Room Sensor module for FX05 12-28°C dial
LP-KIT006-002C
Room Sensor module for FX05 12-28°C dial, occupancy
button, service port
LP-KIT006-003C
Room Sensor module for FX05 +/- dial, occupancy button,
service port
Table 15: Room Command Modules Available Only in North America
Ordering Codes Description
LP-KIT006-004C
Room Sensor module for FX05, warm/cool adjustment
dial, occupancy button, fan speed selector switch, service
port, US mounting kit
LP-KIT006-005C
Room Sensor module for FX05 warm/cool adjustment dial,
occupancy button, US mounting kit
LP-KIT006-006C
Room Sensor module for FX05 setpoint (54-82°F)
adjustment dial, occupancy button, fan speed selector
switch, service port, US mounting kit
LP-KIT006-007C
Room Sensor module for FX05 setpoint (54-82°F)
adjustment dial, occupancy button, service port, US
mounting kit
