Explorer FX15 - FX15 Programming Key Specifications

FX15 Controller Technical Bulletin
57
Programming Key
Table 25: Programming Key
Power Supply
Directly powered from the Display Bus port of the
FX15 or from an AC/DC adapter 230V to 12
VAC ÷ 15 VDC min 2 VA
Memory type and size
Flash memory 1 Mbytes
Connection to controller
Via RS-485, not isolated, 10 cm cable provided
with the key
Enclosure IP class
IP40
Ambient Limits
Operating: 0°C (32°F) – 40°C (104°F), 10-95% rH
(noncondensing)
Storage: -20°C (-4°F) – 70°C (158°F), 10-95% rH
(noncondensing)
Agency Listing
73/23 EEC directive: EN 60730
FX15
Table 26: FX15
Product
FX15
Power Supply
Requirements
24 VAC ±15%, 50/60 Hz - Class 2 Power
Supply
Power Consumption
15 VA at maximum load
Protection Class
IP20 controller
IP40 integrated MUI
Isolation
See Isolation Diagram.
Ambient Operating
Conditions
-20 to +50°C (-4 to 122°F), 10 to 95% rH
(noncondensing)
Ambient Storage
Conditions
-20 to +70°C (-4° to 158°F), 10 to 95% rH
(noncondensing)
Dimensions (H x W x D)
142 mm (5.6 in.) x 215mm (8.5 in.) x 49 mm
(1.9 in.)
Weight (with package)
0.74 Kg (1.6 lb)
I/O ratings
See
I/O Technical Details.
Connection terminals for
signals and power supply
Screw terminals for maximum 1 x 1.5 mm
2
(0.002 in.
2
) wires
or
Cage clamp connectors 1 x 1.5 mm
2
(0.002 in.
2
)
wires
To be ordered separately
LON/N2 Open bus
connection terminals
Screw terminals, cable size 0.05 to 1.5 mm
2
(0.002 in.
2
), AWG30 to AWG14
Belden cable, 2-core twisted pair with shield
Connection terminals for
extension bus and remote
display
Screw terminals, cable size 0.05 to 1.5 mm
2
(0.002 in.
2
), AWG30 to AWG14
Continued on next page…
