FX15 Controller Technical Bulletin
58
Single cable lengths
Digital Inputs DI1 - DI8
Analog Inputs AI1 - AI6
Triac outputs (when present)
Analog Outputs AO1 - AO4
Remote Display
Extension Modules
Display and Extensions
cable type
Maximum 100 m (328.1 ft) with diameters ≥ 0.6
mm (0.02 in.)
Maximum 100 m (328.1 ft) with diameters ≥ 0.6
mm (0.02 in.)
Maximum 100 m (328.1 ft) where A ≥ 1.5 mm
2
(0.002 in.
2
)
Maximum 100 m (328.1 ft) where A ≥ 1.5 mm
2
(0.002 in.
2
)
Maximum 3 m (9.8 ft) if display is powered by
controller. Maximum 1km (1.9 mi) if display
independently powered
Maximum 1km (0.6 mi)
Belden 4-core, twisted pair, shielded
Compliance
89/336 EEC directive: EN 50081-1
(EN 61000-6-3), EN 50082-1 (EN 61000-6-1)
73/23 EEC directive: EN 60730
United States: FCC Compliant to CFR 47, Part
15, Subpart B, Class A
Canada: Industry Canada, ICES-003
UL compliance
UL873 Recognized (XAPX2, XAPX8)
FX15 Extended Range
Table 27: FX15 Extended Range
Product
FX15 extended range
Power Supply Requirements
24 VAC ±15%, 50/60 Hz - Class 2 Power
Supply
Power Consumption
15 VA at maximum load
Protection Class
IP20 controller
IP40 integrated MUI
Isolation
See Isolation Diagram.
Ambient Operating
Conditions
-40 to +60°C (-40 to 140°F), 10 to 95% rH
(noncondensing)
Ambient Storage Conditions
-20 to +70°C (-4 to 158°F), 10 to 95% rH
(noncondensing)
Dimensions (H x W x D)
142 mm (5.6 in.) x 215 mm (8.5 in.) x 49 mm
(1.9 in.)
Weight (with package)
0.74 Kg (1.6 lb)
I/O ratings
See
I/O Technical Details.
Connection terminals for
signals and power supply
Screw terminals for a maximum 1 x 1.5 mm
2
(0.002 in
2
) wires, included in the package.
LON/N2 Open bus connection
terminals
Screw terminals, cable size 0.05 to 1.5 mm
2
(0.002 in.
2
), AWG30 to AWG14, included in
the package.
Belden cable, 2-core twisted pair with shield
Connection terminals for
extension bus and remote
display
Screw terminals, cable size 0.05 to 1.5 mm
2
(0.002 in.
2
), AWG30 to AWG14, included in
the package.
Continued on next page…
