Explorer FX15 - FX15 Technical Specifications; FX15 I;O Technical Details

FX15 Controller Technical Bulletin
54
Technical Specifications
I/O Technical Details
IMPORTANT: For installation with Class 2 inputs and outputs only, no
special mounting precautions are generally necessary. For use with one or
more line voltage outputs (above 30 V), installation as part of a UL 508A
industrial control panel may be required by the local building or electrical
authority. These controllers are presently UL Recognized as Temperature
Indicating and Regulating Equipment in accordance with UL 873. UL Listing as
Open Energy Management Equipment per UL 916 is pending.
Table 19: Analog Input (AI)
Terminals Channel Type Remark/Application
TB1 (1-15)
AI1, AI2, AI3,
AI4, AI5, AI6
See
Figure 30. Software configurable.
Application: temperature,
humidity, pressure
TB1 (3, 8)
EXT-VDC +16 V, 80 mA Directly power from the
controller. Maximum four
0-20/4-20 mA sensors
TB1 (13)
AVPS/EXT-
VDC
AVPS = +5 V, 20 mA
EXT-VDC = +16 V, 80
mA
To directly power
ratiometric sensors,
with AVPS or
0-10 V, 0/4 - 20 mA
Sensors with EXT-VDC.
The selection between
AVPS and EXT-VDC is
done through jumpers.
List of Available Sensor Input
Sensor Type Linearization Range Accuracy
@ 20°C (68°F)
ambient
Ni1000 JCI
-45 to 120 °C (-49 to 248°F) +/- 0.5° C (0.9°F)
Ni1000 JCI Extended
20 to 287°C (68° to 548.6°F) +/- 0.5° C (0.9°F)
Ni1000 Siemens™
-50 to 160°C (-58 to 320°F) +/- 0.5° C (0.9°F)
Ni1000 DIN
-60 to 180°C (-76 to 356°F) +/- 0.5° C (0.9°F)
Pt1000
-50 to 605°C (-58°F to 1121°F) +/- 0.6° C (1.08°F)
A99
-50 to 110°C (-58 to 230°F) +/- 0.5° C (0.9°F)
NTC 2.2K
-40 to 150°C (-40 to 302°F) +/- 0.5° C (0.9°F)
0 to 5 VDC ratiometric
10 to 90% of supply voltage 0.3%
0 to 10 VDC
0 to 10 Volts 0.3%
0 to 20 mA
0 to 20 mA 0.3%
