FX15 Controller Technical Bulletin
59
Single cable lengths
Digital Inputs DI1 - DI8
Analog Inputs AI1 - AI6
Triac outputs (when present)
Analog Outputs AO1 - AO4
Remote Display
Extension Modules
Display and Extensions cable
type
Maximum 100 m (328.1 ft) with diameters ≥
0.6 mm (0.02 in.)
Maximum 100 m (328.1 ft) with diameters ≥
0.6 mm (0.02 in.)
Maximum 100 m (328.1 ft) where A ≥ 1.5 mm
2
(0.002 in.
2
)
Maximum 100 m (328.1 ft) where A ≥ 1.5 mm
2
(0.002 in.
2
)
Maximum 3 m (9.8 ft) if display is powered by
controller. Maximum 1 km (1.9 mi) if display
independently powered
Maximum 1km (0.6 mi)
Belden 4-core, twisted pair, shielded
Compliance
89/336 EEC directive: EN 50081-1
(EN 61000-6-3), EN 50082-1 (EN 61000-6-1)
73/23 EEC directive: EN 60730
United States: FCC Compliant to CFR 47,
Part 15, Subpart B, Class A
Canada: Industry Canada, ICES-003
UL compliance
UL873 Recognized (XAPX2, XAPX8)
The performance specifications are nominal and conform to acceptable industry standards. For
application at conditions beyond these specifications, consult the local Johnson Controls office. Johnson
Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products.
