34
G-10
R
MULTI-BOILER PROGRAMMING
To disconnect the thermostat:
Press the
button for 2 seconds. The thermostat selected will be
disconnected, "OFF" (see fig. 30) will be displayed and the group will start to cool
down.
To connect the thermostat:
If the thermostat is "OFF", press either the
or button. The
thermostat will be connected, the group's current temperature will be displayed and
the group will start to heat up.
Digital thermostat functions
In multi-boiler models, each dispensing group has an independent digital boiler-temperature adjustment system.
The following multi-boiler G-10 models are available:
2 dispensing groups and 3 boilers.
3 dispensing groups and 4 boilers.
Temperature is controlled by a digital thermostat to ensure optimal temperature stability at each group spout.
BUTTONS
HEATER ELEMENT LAMP
GROUP TEMPERATURE
Each group has a numerical display and two buttons: and .
During operation, the displays show the groups' current temperature.
The dot indicates when the heater elements are active.
Connecting/disconnecting each thermostat
Fig. 30
