G-10 2Gr 3 Boilers: boiler assembly (main boiler)
DETAIL DRAWINGS
Part list
POS. PCS Part No. Description
01 1 C60100076 Temp. Probe + Susp. Steam Pipe Icd
02 1 C30000003 Reducer Male-Female-3/8 - 1/4
03 1 C30000290 Plug M 3/8
04 1 C65000200 Non Suction Valve
05 2 C30000315 Bling Plug 1/8 Female
06 2 C30000510 Conical Adaptor 1/4*1/4 Electron
07 2 C30000220 Cone Injector 1/4
08 2 C50010020 13.2*18.2*2.5 1/4 Teon Gasket
09 2 C30000210 Thermics Inf. Adaptor-1/2X1/2X1/4
10 1 C65000110 Cn10 Ptfe Ce Safety Valve
11 2 C50010010 21.1*25.7* 1/2 Teon Gasket
12 1 C30000100 2 Tracks Adaptor- 1/4 X 1/8
13 1 C38027000 3050W.230V- 2Gr Element
*13 1 C38045000 4500W-230V 2GR ELEMENT
*13 1 C38060000 6000W.230V-3GR ELEMENT
14 1 C50010030 40*52*2 Element Teon Gasket
15 1 C15100020 Boiler 2Gr 11Lts.
*15 1 C15100030 Boiler 3Gr 17Lts.
16 2 C30200035 Long Plug 1/2 Group
17 1 C25679812 M12 Washer Form A
18 1 C25000003 Inox Ground Washer
19 1 C60100040 Water Level Probe 1/4
20 1 C30000110 3 Tracks Adaptor 1/4 * 1/4 * 1/8
21 2 C50010050 3/8 Boiler's Connector Teon Gaske
