Expobar G-10 Service Manual

63
G-10
R
G-10 2Gr 3 Boilers: boiler assembly (group boiler)
Part list
POS. PCS Part No. Description
01 1 C30000220 Cone Injector 1/4
02 1 C50010020 13.2*18.2*2.5 1/4 Teon Gasket
03 2 C25091210 Allen Screw 4X12 Din-912
04 1 C10200110 Ofce Thermostat 16 A
05 1 C30000290 Plug M 3/8
06 1 C38012000 1200W-230V Ofce Element
07 2 C30000300 Blind Plug 1/4 Male
08 1 C15100010 Ofce Cappuccinator Boiler
09 1 C60100076 Temp. Probe + Susp. Steam Pipe Icd
10 2 C50010010 21.1*25.7* 1/2 Teon Gasket
11 2 C30000200 Thermics Sup. Adaptor 1/2 X 1/2
DETAIL DRAWINGS
