Expobar G-10 Service Manual

51
G-10
R
DETAIL DRAWINGS
Part list
G-10 Mini 2Gr: water system
POS. PCS Part No. Description
01 1 C15000370 Tap Steam Eleg./Mega Comp 4H Bf
02 1 C60000062 D-40 One Reading Manometer Orman
03 1 C35040117 4Ltrs Grinder's Steam Pipe
04 1 C35110530 Pipe Manometer
05 2 C15000050 Group Espresso Preass
06 1 C35040006 Pipe Group Left Return Mini
07 1 C35110002 Pipe Group Right Inlet
08 1 C35110003 Pipe Group Left Inlet
09 3 CESC00100 Magnets Set
10 1 -------- Boiler Assembly G-10 Mini
11 1 C35040106 Pipe Pressure Sensor Mini
12 1 C60000008 Pressostat Piris Ce
13 2 C35040118 Pipe Water Filling Mini
14 1 C35040105 Pipe Group Right Return Mini
15 1 C15000330 Tap Hot Water Complete
16 1 CESC00098 Piping Mini Control 2 Std&Ta
17 1 C70001005 Drain Cup Cover
18 1 C70001001 Drain Cup With Thread
19 1 CESCMPE00 Motor&Pump Ass Eco
20 1 C35900040 55Cm Hose
21 1 C35900180 180Cm Hose
