53
G-10
R
G-10 2Gr: water system
DETAIL DRAWINGS
Part list
POS. PCS Part No. Description
01 1 C35900020 30Cm Hose
02 2 C15000370 Tap Steam Eleg./Mega Comp 4H Bf
03 1 C35040117 4Ltrs Grinder's Steam Pipe
04 1
C35110465 Pipe Water Filling 2Gr Mc
05 1 C15000330 Tap Hot Water Complete
06 1 C35110005 Pipe Water Tap
07 2 C15000050 Group Espresso Preass
08 1 C35110003 Pipe Group Left Inlet
09 3 CESC00100 Magnets Set
10 1 C35110002 Pipe Group Right Inlet
11 1 -------- Boiler Assembly G-10 2Gr
12 1 C35110113 Pipe Steam Tap
13 2 C35110000 Pipe Group Right Return 2Gr
14 1 C35040007 Flowmeteroutlet Piping
15 1 C35040104 Volumetric Tube Laberinth Mc
16 1 C35110461 Manifold Tube Distributor 2Gr
17 2 C60100045
Flowmeter Ul/Netw. Brass Tef+Led
18 1 C35110012 Pipe Drainage Boiler 2Gr
19 1
CESC00093 Water Spliter
20 1
C70001000 Drain Filter + High Group
21 1 CESCMPS00 Motor&Pump Ass Std
22 1 C35900180 180Cm Hose
*23 2 C35040103 Volumetric Tube
*24 1 C35110464 Pipe Distribution 2Gr Mc
25 - CESC00060 Flowmeter Ass
Note:
In models designed for tall cups, parts 14, 15 and 16 are replaced by parts 23 (x2) and 24.
