Expobar G-10 Service Manual

73
G-10
R
DETAIL DRAWINGS
Part list
G-10 2Gr: water supply and drainage set
POS. PCS Part No. Description
01 1 C60000105 50/60Hz 220V Solenoid Electrovalve
02 1 C50000105 Large Autoll Solenoid Gasket
03 1 C50000110 Small Autoll Solenoid Gasket
04 1 C30000215 Conical Bend Adaptor 1/4 X 1/4
05 3 C30100010 Hexagonal Nut 1/4 Pressostat
06 1 C30100033 Distributor Mc
07 1 1860016 Tap Drainage G1/4M-G1/4F Right
08 1 C30369100 Relief Valve Body
09 1 C50000020 Gasket For Motor
10 1 C55000030 Expansion Valve Spring
11 1 C50010040 21.7*25.7*2 G/C-G Teon Gasket
12 1 C30369135 Barb Fitting 1/2 * 1/4 G/C
13 1 C30369110 HOUSING RING
14 1
C50000130 O-Ring 8 X 1.9
15 1 C65000031 Retent+Expans.Valve Set No Hole
16 1 C65000020 Expansion Valve Complete
17 1 CESC00093 Water Spliter
Important:
When ordering a replacement for electrovalve no. 1, specify if the machine operates
at 230 V or 120 V.

Expobar G-10 Specifications

General

Brand	Expobar
Model	G-10
Category	Coffee Maker
Language	English
