Page #77 background imageLoading...
Page #77 background image
77
G-10
R
POS. PCS Part No. Description
01 1 C30370070 Tap Body
02 1 C30370060 Close Nut
03 1 C30370050 Closing Shaft M-6
04 1 C30370040 Shaft Spring
05 1 C30370065 Push Cap
06 2 C30370020 Shaft Ring
07 1 C30370030 Gasket
08 1 C30370010 Tap Fitting
09 1 C30370140 Tap Fixing Nut
10 1 C40000015 High Group Tap Knob
11 1 C25012521 Stainless Steel Knob Washer
12 1 C30370110 Water/Steam Knob Pin
13 1 C30370130 Steam Tap Knob Anagram
14 1 C30370120 Water Tap Knob Anagram
15 1 C25097960 Steam/Water Tap Nut M6-Din 979
16 1 C50010080 Gasket Tap Steam/Water Teon
17 1 C30370076 Spring Steam/Water Tap
18 1 C30370077 Gasket Tap Steam/Water Brass
19 1 C30370075 O-Ring 12.1X2.7mm
20 1 C70000010 Nut 3/8 For Steamer
21 - C15000325 Tap Steam/Water Body
22 - C30370080 Lanza Agua Mod Classic
23 - C30000050 Nozzle Water Tap Complete
24 - C35010056 Hot Water Pipe For High Group
25 - C15000330 Tap Hot Water Complete
Hot water taps
DETAIL DRAWINGS
Part list
