Section 1
General
Pilot´s Operating Handbook
EXTRA 300S
1.3.2 Main Data
- Length 6,65 m (21,82 ft)
- Height 2,62 m (8,60 ft)
- Span 7,50 m (24,61 ft)
- Wheel-base 1,80 m (5,91 ft)
- Wheel-track 4,75 m (15,58 ft)
1.3.3 Wing
- Wing span 7,5 m (24,61 ft)
- Wing-area 10,44 m² (112,38 ft²)
- Airfoil Root: MA 15 S. Tip: MA 12 S
- Chord Root: 1,85 m (6,07 ft)
Tip: 0,93 m (3,05 ft)
- MAC 1,44 m (4,72 ft)
- Aileron area 2 x 0,830 m² (2 x 8,93 ft²)
- Aileron deflection ± 30°, tolerance ± 2°
1.3.4 Horizontal Tail
- Span 3,20 m (10,50 ft)
- Area 2,56 m² (27.56 ft²)
- Airfoil Wortmann FX 71-L-150/30
1.3.5 Elevator
- Area 0,77 m² (8,29 ft²)
- Elevator-deflection up 26°; down 26°; tolerance ± 2°
- Trim-tab-deflection ± 15°, tolerance ± 2°
1.3.6 Vertical Tail
- Area 1,39 m² (14,96 ft²)
- Airfoil Wortmann FX 71-L-150/30
1.3.7 Rudder
- Area 0,51 m² ( 5,49 ft²)
- Rudder deflection left 30°; right 30°; tolerance ± 2°
