Page Date: 20. April 2002 5 - 13
Section 5
Performance
Pilot´s Operating Handbook
EXTRA 300S
NOTE
5.10 CRUISE PERFORMANCE
Range and Endurance values for a T/O Weight of 920 kg (2028 lbs) including fuel for warm-
up and Take-Off from SL, max. cont. Power climb to cruising altitude, and a reserve of 21
liters (5.55 Gal) for 45 minutes with 45% Power. 2 liters (0.53 Gal) unusable fuel is taken
into account. (At ISA - Conditions.)
PA Eng. Manif. Power Setting Fuel TAS IAS Endur. Range Mixture
Press. Consumption 1 1 2
[ft] [RPM] [IN HG] [%] [Hp] [l/h] [gal/h] [Kts] [Kts] [h] [NM] Best ...
2000 2400 25,1 75 225 68,7 (18,2) 167,6 160 1.91 320 Power
2200 24,2 65 195 50,5 (13,3) 159,3 152 2.60 413 Economy
2000 23,5 55 165 42,6 (11.3) 150,2 144 3.08 462 Economy
2000 20,2 45 135 36,5 (9,6) 139,9 134 3.59 502 Economy
4000 2400 24,6 75 225 68,7 (18,2) 170,9 158 1.91 324 Power
2200 23,7 65 195 50,5 (13,3) 162,4 150 2.59 418 Economy
2000 23,0 55 165 42,6 (11,3) 153,1 142 3.06 467 Economy
2000 19,7 45 135 36,5 (9,6) 142,6 133 3.59 507 Economy
6000 2200 23,2 65 195 50,5 (13,3) 165,6 149 2.57 422 Economy
2000 22,5 55 165 42,6 (11.3) 156,1 141 3.04 472 Economy
2000 19,3 45 135 36,5 (9,6) 145,4 131 3.53 512 Economy
8000 2350 21,5 65 195 52,0 (13,7) 169,0 147 2.49 415 Economy
2050 21,4 55 165 43,0 (11,4) 159,3 139 2.99 472 Economy
2000 18,8 45 135 36,5 (9,6) 148,4 130 3.51 517 Economy
10000 2150 19,9 55 165 43,7 (11,5) 162,5 138 2.93 469 Economy
2000 18,4 45 135 36,5 (9,6) 151,4 129 3.48 522 Economy
12000 2300 18,3 55 165 45,2 (11,9) 165,9 136 2.81 458 Economy
2000 17,9 45 135 36,5 (9,6) 154,5 127 3.44 526 Economy
14000 2400 17,0 55 165 46,7 (12,3) 169,4 135 2.71 446 Economy
2075 17,7 45 135 37,1 (9,8) 157,8 122 3.36 520 Economy
1 For temperatures above/ below Standard (ISA), increase/decrease Range 1,7% and
Endurance 1,1% for each 10°C above/below Standard Day Temperature for particular
altitude.
2 "Best Power" or "Best Economy" see latest issue of Textron Lycoming Operator`s
Manual (4-10) Series AEIO 540.
