Page Date: 20. April 2002 2 - 9
Pilot´s Operating Handbook
EXTRA 300S
Section 2
Limitations
THE REMAINING FUEL IN LEVEL FLIGHT (on the instrument panel
CANNOT BE USED SAFELY under the acro & center tank
WHEN INDICATOR READS "ZERO". fuel capacity indicator)
ACROBATIC: ± 10 G (in cockpit)
MTOW 820 KG (1808LBS)
NORMAL : + 6 G/- 3 G
MTOW 920 kg (2028 LBS)
ACROBATICS INCL. SPIN NOT APPROVED
OFF (under pump switch on the instrument panel)
BOOST PUMP
NO SMOKING (on canopy frame)
USE OF HEADSET IS REQUIRED (on the right side of
USE OF PARACHUTE IS RECOMMENDED instrument panel)
LOW RPM <= PROP => HIGH RPM (on RPM control unit in the
rear cockpit)
RICH <= MIXTURE => LEAN (on mixture control unit in the
rear cockpit)
CLOSE <= THROTTLE => OPEN (near throttle control in both
cockpits)
CANOPY LOCK
LOCK <= O => UNLOCK <= O => LOCK (near canopy locking handles
of each cockpit)
V E N T (near the eyeball-type adjustable vents)
O P E N
CAUTION
Particular caution must be exercised when performing (in cockpit)
maneuvers at speeds above Va (158 KIAS). Large or
abrupt control inputs above this speed may impose un-
acceptably high loads which exceed the structural
capability of the aircraft.
Page Date: 20. September 2006
