Extra 300S - Page 77

Page Date: 20. April 2002 6 - 11
Section 6
Weight and Balance and Equipment List
Pilot´s Operating Handbook
EXTRA 300S
1 Governor Woodward A- 210 988 1.10 -0.91 R
1 Governor MT-Propeller P-880-5 1.10 -0.91 A
7 Switches Cutler Hammer div. 0.28 1.31 R
7 Switches Kissling div. 0.28 1.31 A
11 Circuit Breaker Potter&Brumfield div. 0.50 1.29 R
11 Circuit Breaker ETA or Klixon div. 0.30 1.29 A
1 Main Bus Fuseholder MTA 03.00360 0.03 0.02 O
1 Main Bus Strip Fuse MTA 02.00300 O
(40 Amps)
1 PCB Auto Fuse EXTRA 83290.1 0.01 0.02 O
1 Fuel Cont. Probe VDO 226 801 015 001 G 0.12 0.33 R
Wing Tank
1 Fuel Cont. Probe VDO 224 082 007 004R 0.19 0.68 R
Center Tank
1 Fuel Cont. Ind. VDO 301 271 036 001 K 0.08 1.30 R
Wing Tank or 301 030 001 G
1 Fuel Cont. Ind. VDO 301 272 052 001 K 0.14 1.30 R
Acro Tank or 301 030 002 G
1 Ammeter VDO 190 004 039 002 0.08 1.31 R
or 190 037 002 G
1 Volt/Ammeter Electronics Intern. VA-1A 0.26 1.30 A
1 Shunt Electronics Intern. S-50 0.09 1.20 A
1 Volt/Ammeter Electronics Intern. VA-1A-50 0.22 1.30 A
1 RPM Indicator VDO 333 230 115 002 0.31 1.28 R
or 333 035 001 G
1 RPM Indicator digital Horizon P100-230-643-00 0.68 1.28 A
1 Magn. Dir. Ind. Airpath C 2300 0.25 1.30 R
1 Oil Press./ AMITEK or Christen 61943 0.51 1.30 R
Oil Temp. Ind.
1 Oil Press./ Westach 3DA3-3MM 0.14 1.30 A
Oil Temp. Ind. (3 1/8") or 3DA3-3KV
1 Oil Temp. Sender Westach W399-S9 0.08 -0.11 A
1 Oil Press Sensor Mediamate 387-100MM 0.12 0.04 A
or 387-100KV
1 Oil Press / Westach 2DA3-3MM 0.09 1.30 A
Oil Temp Ind. (2 1/4") or 2DA3-3KV
1 Oil Temp. Sender Westach W399-S9 0.08 -0.11 A
1 Oil Press Sensor Mediamate 387-100MM 0.12 0.04 A
or 387-100KV
1 Stall Sensor EXTRA 73106.1 0.07 0.27 R
1 Stall Warning Horn EMAG EM-S 110P 0.13 1.20 R
1 G-Meter EXTRA DSA 12 0.37 1.28 O
1 G-Meter Kollsman or Pioneer AN5745 0.40 1.28 O
or Bendix
1 G-Meter EZE Technologies DA-55 0.16 1.28 O
1 ELT and Antenna Pointer 3000-10 0.90 0.72 O
1 Turn & Bank Ind. United Instruments 9501-2 / TSO C3b 0.55 1.28 O
1 Turn & Bank Ind. Castleberry C101 / TSO C101T 0.55 1.28 O
1 Altimeter United Instruments UI5934PD-3 A.134 0.60 1.30 R
QTY ITEM MANUFACT. PART OR P/N WEIGHT ARM MARK IF REQUIRED (R)
(KG) (m) INSTALLED OPTIONAL (O)
ALTERNAT. (A)
Page Date: 31. January 2006
