Page Date: 20. April 2002 6 - 13
Section 6
Weight and Balance and Equipment List
PilotĀ“s Operating Handbook
EXTRA 300S
1 Main Bus Solenoid White-Rodgers 70-111-226-5 0.40 0.02 R
1 Starter Solenoid Switches Kidde 22735 0.40 0.02 R
1 Low Voltage Light OAK MS25041-2 0.02 1.31 R
1 Ignition TCM 10-357200-1 0.15 1.30 R
Switch
2 Wheel Cleveland 40-151 4.00 0.16 R
2 Main Wheel Tires Div 5.00-5 / 6PR 3.90 0.16 R
1 Tail Wheel 5" EXTRA steerable 5.50 4.91 A
1 Tail Wheel 5" EXTRA free swivel type 5.50 4.91 R
1 Tail Wheel 6" Assy Special Products 5.90 4.91 A
(Soft) Aviation Inc.
2 Brake Assy Cleveland 30-164 1.40 0.16 R
2 Brake Cyl. Cleveland 10-20 or 10-20E 0.55 0.89 R
2 Brake Cyl. Matco MC-4E 0.55 0.89 A
1 Brake Fluid Reservoir EXTRA 53301.1 0.20 0.03 R
1 Brake Fluid Reservoir ACS A-315 0.20 0.04 A
1 Safety Belt Hooker 1 011 230 3.30 1.95 R
Assy with ratchet
2 NAV/STROBE LTS Whelen A 600-PG/PR-14 0.23 0.56 R
2 Power Supply Whelen A490T 0.54 0.56 R
2 Electric Actuator SKF CARR 3.25 0.65 R
Pedal Adjust. 22x200x1/D12B
1 Long Range Tank EXTRA 84901 1.80 0.38 O
1 Fuel Selector Spruce 108HD-04 0.30 0.56 R
1 Fuel Selector Allen 6 S 122 0.19 0.56 A
1 Safety Cover EXTRA 84803.1 2.53 2.80 O
(Polycarbonate)
1 Dual Pump EXTRA 84100 6.40 0.20 O
Smoke System
without Pumps
2 Smoke Oil Pump ITT Jabsco 8860-1203 3.60 0.20 O
(Inject. and Refill)
2 Smoke Oil Pump ITT Jabsco 23620-3003 4.40 0.20 O
(Inject. and Refill)
1 Smoke Oil Pump Johnson F3B-19 (12V) 2.00 -0.05 O
(Injection)
1 Smoke Oil Pump Johnson F2P10-19 (12V) 1.65 0.35 O
(Refill)
1 Single Pump EXTRA 84112 6.80 0.19 O
Smoke System
incl. Pump Marco UP3/OIL 12V
1 Airtow Hook EXTRA/TOST 83607A0 0.50 5.10 O
1/2 Sighting Dev. LH/RH EXTRA 84801.10 each 0.44 1.25 O
1 Aresti-Card Holder EXTRA Assy 0.09 1.32 O
2 Wing Tie Down Rings EXTRA 83801.2-01 0.04 0.95 O
QTY ITEM MANUFACT. PART OR P/N WEIGHT ARM MARK IF REQUIRED (R)
(KG) (m) INSTALLED OPTIONAL (O)
ALTERNAT. (A)
Page Date: 20. September 2006
