COMFORT MAXI INSTALLATION
Chapter 7
Air inlet box
Air inlet box
As far as the air inlet box is concerned, there is the possibility to connect the air inlet pipe above the sliding
base (see picture above) or under it (see picture below) depending on the needs.
All these operations must be carried out by a specialized technician.
 gure 7.15
 gure 7.16
