Table 10: SFP transceivers
Model Description Part number
Important:
The following SFP transceivers with the part numbers:AA1419013–E5, AA1419014–E5, AA1419015–
E5, and AA1419025–E5 to AA1419040–E5. However
, Extreme Networks recommends using the newer
DDI versions of these SFP transceivers.
1000BASE-T SFP Gigabit Ethernet, RJ–45connector AA1419043–E6
1000BASE-SX DDI SFP 850 nm, GigabitEthernet, duplex
LC connector
AA1419048–E6
1000BASE-LX DDI SFP 1310 nm, GigabitEthernet, duplex
LC connector
AA1419049–E6
1000BASE–ZX DDI CWDM 70 km
SFP
Gigabit Ethernet,duplex LC
connector
AA1419065-E6
1000BASE-BX10 DDI SFP 1310 nm (tx) and 1490 nm (rx) AA1419069–E6 (10 km at 1310
nm ) and mating pair AA1419070–
E6 (10 km at 1490 nm)
00BASE-FXSFP 1300 nm, 100Mbps Ethernet,
multimode fiber, duplex LC
connector
AA1419074–E6
Small Form-Factor Pluggable Plus (SFP+) Transceivers
SFP+ transceivers are hot-swappable input and output enhancement components that allow 10
gigabit connections. All SFP+ transceivers use Lucent connectors (LC) to provide precision keying
and low interface losses.
For more information about transceiver use and designation, see Extreme Networks Pluggable
Transceivers Installation Guide.
Operating Power Considerations
When you connect the device to collocated equipment, ensure that enough optical attenuation exists
to avoid overloading the receivers of each device. You must consider the minimum attenuation
requirement based on the specifications of third-party equipment.
For more information about transceiver use and designation, see Extreme Networks Pluggable
Transceivers Installation Guide.
Checking Status LEDs to V
erify Switch Installation
Perform this procedure to verify the hardware installation and operation of the unit.
The status LEDs on the front of the unit indicate the installation and operational status of the
hardware.
Installing the Switch
February 2020 Installing Ethernet Routing Switch 3600 Series 34
