RJ45 console port pin-out Signal Requirement
6 RXD (receive data) Mandatory
7 DSR (data set ready) Optional
8 CTS (clear to send) Optional (can be swapped or
linked with pin
USB Port
The USB port is a Standard T
ype-A female USB 2.1 port. The switch provides USB host
functionality and can support USB flash drives.
Console and Management Connections
February 2020 Installing Ethernet Routing Switch 3600 Series 41
