AP560h Features
The AP560h access point has the following features:
• Radios: Two radios
◦ 1 dual-band, 2.4GHz and 5GHz, and 1 band-locked 5GHz
◦ 1 IoT Radio (2.4 GHz)
• Two Ethernet ports
◦ 1 x 100/1000/2500/5000 Mbps auto-negotiation Ethernet port, RJ45
◦ 1 x 10/100/1000 Mpbs auto-negotiation Ethernet port, RJ45
• Dimensions: 11.3 in. × 18.9 in. × 3.5 in. (288 mm × 481 mm × 88 mm)
• LEDs: Two top-mounted LEDs
• One security hanger hole
• Power: PoE 802.3at
• Antennas:
◦ Two software selectable internal antennas (30 degree and 70 degree directional
antennas)
• Temperature:
◦ Operating temperature: -40°C to +55°C (-40°F to +131°F)
◦ Storage temperature: -40°C to +70°C (-40°F to +158°F)
• Enclosure: Plastic only
Figure 1: AP560h front view
AP560h Features AP560h Overview
10 ExtremeWireless™ AP560h Access Point
