Procedure
1. Verify that the box contains the following items:
Quantity Item
1 AP560h Quick Reference
1 AP560h access point
2. Verify the purchase order information of the bracket or accessory you have ordered
to install the access point.
Access Point Bracket Usage and Mounting Options
Details about various mounting brackets and accessories that can be used with the
access point during wall or pole installation.
The access point is mounted on a wall or to a pole, the details of which are described in
the following table:
Table 6: AP560h mounting brackets and accessories usage
Mounting bracket/
accessory and part
number
Wall install Pole install Notes
KT-147407-02
bracket; comes with
three bracket parts
Yes Yes For attaching to a
wall or a at surface,
use the bracket
part that has two
holes metal surface.
For attaching to
a pole, attach the
KT-147407-02 pole
part on top of the 1-
axis tilt part.
KT-150173-01;
extension arm; used
with KT-147407-02
bracket parts
Yes; place
the KT-150173-01
extension arm on
top of the 1-axis
KT-147407-02 tilt
part
Yes; attach the
KT-147407-02 pole
part to the
extension arm
None.
Access Point Bracket Usage and Mounting Options Install the Access Point
16 ExtremeWireless™ AP560h Access Point
