MLC Plus 50/100/200 Series • Hardware Features and Installation 11
Write down the MAC address of each IPLinkPro device (such as the
MLCPlus50/100/200) to be used.
Obtain model names and setup information for devices the MLC Plus 50/100/200 will control.
Installation Step 2: Prepare the Installation Site
Steps and hardware required depend on the model being installed (see Site Preparation
on page12 for details)
ATTENTION:
• Installation and service must be performed by authorized personnel only.
• L’installation et l’entretien doivent être effectués uniquement par un technicien
qualifié.
• Extron recommends installing the MLC Plus 50/100/200 into a grounded, UL
Listed electrical junction box.
• Extron recommande d’installer le MLC Plus 50/100/200 dans un boîtier
d’encastrement électrique mis à la terre, certifié UL.
• If the controller will be installed into fine furniture, it is best to hire a licenced,
bonded craftsperson to cut the access hole and perform the physical installation
so the surface will not be damaged.
• S’il est prévu d’installer le contrôleur dans du beau mobilier, il est préférable de
faire appel à un artisan autorisé et qualifié pour couper le trou d’accès et réaliser
l’installation de telle façon que la surface ne soit pas endommagée.
• Follow all national and local building and electrical codes that apply to the
installation site.
• Respectez tous les codes électriques et du bâtiment, nationaux et locaux, qui
s’appliquent au site de l’installation.
NOTES:
• For the installation to meet UL requirements and to comply with National
Electrical Code (NEC), the MLC must be installed in a UL Listed junction box.
The end user or installer must furnish the junction box. It is not included with the
MLCPlus50/100/200.
• If the MLC Plus is not mounted to a grounded metal junction box or a grounded
metal equipment rack, Extron recommends connecting the unit to an earth ground
to protect the unit from electrostatic discharge. For details, see the grounding
instructions on page15.
• If not provided with a power supply, this product is intended to be supplied by a
power source marked “Class 2” or “LPS” and rated at 12VDC, minimum 0.5A, or
48V PoE, 0.35A minimum, or 56V PoE, 0.8A minimum.
Select and prepare the site before cabling the controller. This may include cutting a hole
in the installation surface or installing a cabling raceway, running the cables to that site,
installing the wall box, and pulling cables through it.
Accessibility and Americans with Disabilities Act (ADA) Compliance
When planning where to install the MLCPlus50/100/200, consider factors affecting accessibility
of the controller such as height from the floor, distance from obstructions, and how far a
user must reach to press the buttons. For guidelines, see sections 307(“Protruding Objects”)
and 308(“ReachRanges”) of the 2010 ADA Standards for Accessible Design available at
http://www.ada.gov/regs2010/2010ADAStandards/2010ADAStandards.pdf.
