SW HD 4K PLUS Series • Remote Configuration and Control 21
X1^
= Output HDCP status
0 = No sink detected
1 = Sink with HDCP detected
2 = Sink without HDCP detected
X1&
= Output HDCP mode
0 = (Default) Encrypt as required by input.
For HDMI sinks, perform continuous trials.
For DVI sinks, attempt for 10 seconds, then fail.
1 = Always encrypt.
For HDMI sinks, perform continuous trials.
For DVI sinks, attempt for 10 seconds, then fail.
2 = Encrypt as required by input. Continuous trials for HDMI and DVI sinks.
3 = Always encrypt. Continuous trials for HDMI and DVI sinks.
X1*
= Tally pin mode for channel mute indicator
0 = Always on (default)
1 = Off when muted
2 = Blink when muted
NOTE: Unless otherwise indicated, commands are not case-sensitive.
X1(
= Local date and time (to set): MM/DD/YY-HH:MM:SS
X2)
= Local date and time (displayed): Ddd, DD Mmm YYYY HH:MM:SS
X2! = IP address (nnn.nnn.nnn.nnn) Leading zeros in each of the four octets are optional in
setting values and are suppressed in returned values.
X2@
= Hardware media access code (MAC) address (00-05-A6-XX-XX-XX). The MAC address
is view-only and cannot be changed.
X2#
= Subnet mask (nnn.nnn.nnn.nnn)
X2$
= Gateway IP address (nnn.nnn.nnn.nnn)
X2%
= Domain name system (DNS) server IP address (nnn.nnn.nnn.nnn)
X2^
= Administrator password
X2&
= User password
NOTES:
• In response to the View administrator password and the View user password
commands,
X2^
and
X2&
are displayed as **** if a password exists. An empty line is
displayed if no password exists.
• The factory configured passwords for all accounts on this device have been set to the device
serial number. In the event of an absolute system reset, the passwords convert to the default,
which is no password.
X2* = Network Time Protocol (NTP) IP address or URL
X2( = Serial port number — Two ASCII characters (00 not permitted)
X3) = Baud rate: 300, 600, 1200, 1800, 2400, 3600, 4800, 7200, 9600 (default), 14400,
19200, 28800, 38400, 57600, or 115200
X3! = Parity: Odd, Even, None (default), Mark, Space
(Use only the first letter.)
X3@ = Data bits: 7 or 8 (default)
X3#
= Stop bits: 1 (default) or 2
X3$
=
Time zone code
The code is an acronym for the time zone (2-6 letters) (see the List all time zones
command on page 30 to view a list of available time zones).
