SW HD 4K PLUS Series • Remote Configuration and Control 24
Command
ASCII Command
(Host to Switcher)
Response
(Switcher to Host)
Additional Description
Auto‑input Switch Mode (continued)
Set time-out duration for
mode 2
E
T
X(
AUSW
}
Ausw T
X(]
Set the number (
X(
) of seconds
(0 - 250) the switcher delays
before switching to the most
recently applied input.
0 = immediate switch (no delay)
View mode 2 timeout duration
E
T AUSW
} X(]
In verbose modes 2 and 3:
Ausw T
X(]
View the mode 2 timeout
X(
.
KEY:
X(
= Auto-input switch mode 2 1-250 = Number of seconds the switcher delays before switching to the
timeout duration most recently selected input.
0 = Immediate switch (no delay)
Video Color Bit Depth
Set video color bit depth
mode
E
V
X#
BITD
}
BitdV
X#]
Select color bit depth mode
X#
.
View video color bit depth
mode
E
V BITD
} X#]
In verbose modes 2 and 3:
BitdV
X#]
View the video color bit depth.
KEY:
X#
= Video color bit depth mode 0 = Automatically truncate based on the EDID of the connected output
(default)
1 = Force truncation to 8-bit
Signal Status
Request status of all signals
E
LS
} X@
•
X@
•...•
X@
•
X@
*
X@]
In verbose modes 2 and 3:
Sig
X@
•
X@
•...•
X@
*
X@]
View signal status
X@
of all inputs,
followed by the output (*
X@
).
KEY:
X@
= Input and output signal status 0 = no signal detected (default), 1 = signal detected
Output 5 V Mode
Set output 5 V mode
E
M
X1$
HPLG
}
Hplg M
X1$]
Select output 5 V mode
X1$
.
View output 5 V mode status
E
MHPLG
}
X1$]
In verbose modes 2 and 3:
Hplg M
X1$]
View current output 5 V mode.
KEY:
X1$
= Output 5 V mode 0 =
Auto: 5 V is enabled only when a source with 5 V is present.
1 =
5 V is always enabled (default).
Front Panel Lockout (Executive Mode)
Enable or disable lock mode
X@
X Exe
X@]
Select front panel lock mode
X@
.
Query lockout status
X
X@]
In verbose modes 2 and 3:
Exe
X@]
Show executive mode status.
KEY:
X@
= Front panel lock mode 0 = lock mode off (default), 1 = lock mode on
