SW HD 4K PLUS Series • Remote Configuration and Control 25
Command
ASCII Command
(Host to Switcher)
Response
(Switcher to Host)
Additional Description
HDCP Commands
HDCP Status
View HDCP status for an
input
E
I
X!
HDCP
} X1%]
In verbose modes 2 and 3:
Hdcp I
X1%]
Show HDCP status
X1%
for input
X!
.
X!
= 1 through {maximum
number of inputs}.
View HDCP status for all
inputs
E
IHDCP
}
X1%
•
X1%
•...•
X1%]
In verbose modes 2 and 3:
Hdcp I
X1%
•
X1%
•...•
X1%]
Show HDCP status
X1%
for all the
inputs.
View output HDCP status
E
OHDCP
} X1^]
In verbose modes 2 and 3:
Hdcp O
X1^]
Show HDCP status
X1^
for the
output.
HDCP Input Authorization
HDCP authorization per
input
E
E
X!
*
X@
HDCP
}
Hdcp E
X!
*
X@]
Set HDCP authorization for input
X!
to
X@
.
Enable or disable HDCP
authorization for all inputs
E
E
X@
HDCP
}
Hdcp E
X@]
Set HDCP authorization to
X@
for
all inputs.
View HDCP authorization
status for all inputs
E
EHDCP
}
X@
•
X@
•...•
X@]
In verbose modes 2 and 3:
HdcpE
X@
•
X@
•...•
X@]
View the current HDCP
authorization setting
X@
for all the
inputs.
Output HDCP Mode
Set the output HDCP mode
E
S
X1&
HDCP
}
Hdcp S
X1&]
Set the output HDCP mode to
X1&
.
View the output HDCP mode
E
SHDCP
} X1&]
In verbose modes 2 and 3:
Hdcp S
X1&]
View HDCP mode
X1&
for the
output.
KEY:
X!
= Input number 1 through the highest numbered input on the unit (2 through 8,
depending on the model)
X@
= Enable or disable HDCP 0 = Disable HDCP authorization, 1 = Enable HDCP authorization (default)
authorization
X1%
= Input HDCP status
0 = No source detected, 1 = Source with HDCP detected,
2 = Source without HDCP detected
X1^
= Output HDCP status
0 = No sink detected, 1 = Sink with HDCP detected
2 = Sink without HDCP detected
X1&
= Output HDCP mode 0 = (Default) Encrypt as required by input:
For HDMI sinks, perform continuous trials.
For DVI sinks, attempt for 10 seconds, then fail.
1 = Always encrypt:
For HDMI sinks, perform continuous trials.
For DVI sinks, attempt for 10 seconds, then fail.
2 = Encrypt as required by input: continuous trials for HDMI and DVI
sinks.
3 = Always encrypt: continuous trials for HDMI and DVI sinks.
