SW HD 4K PLUS Series • Remote Configuration and Control 26
Command
ASCII Command
(Host to Switcher)
Response
(Switcher to Host)
Additional Description
TMDS Output Format
Set the output format
EX1!
VTPO
}
Vtpo
X1!]
Set the TMDS output format
X1!
.
View the output format
setting
E
VTPO
} X1!]
In verbose modes 2 and 3:
Vtpo
X1!]
Show TMDS output setting
X1!
.
KEY:
X1!
= Output format 0 = Auto (default),
1 = DVI RGB 444
2 = HDMI RGB “Full”
3 = HDMI RGB “Limited”
4 = HDMI YUV 444 “Limited”
5 = HDMI YUV 422 “Limited”
Unit Name
Set unit name
24
EX&
CN
}
Ipn•
X&]
Assign name
X&
for the switcher.
X&
can
Set name to factory default
24
E
•CN
}
Ipn•SWn-HD-4K-PLUS-XX-XX-XX
]
SWn = SW2, SW4, SW6, or SW8
xx-xx-xx = Last 6 characters of the
switcher MAC address.
View unit name
E
CN
} X&]
In verbose modes 2 and 3:
Ipn•
X&]
Show the current switcher name
X&
.
KEY:
X&
= Unit name Consists of up to 24 alphanumeric characters, including the hyphen (-).
Channel Mute Mode — via contact and tally pins
Set mode
EX@
*
X1*
MUTM
}
Mutm
X@
*
X1*]
Mute (deselect) or unmute (select)
the connected contact input and
set the tally pin mode (
X1*
) for the
input).
Set the behavior of the connected
tally indicator to
X1*
when the
output mute
X@
is set to 1.
View mode
E
MUTM
} X@
*
X1*]
In verbose modes 2 and 3:
Mutm
X@
*
X1*]
View channel mute mode
X@
and
tally mode
X1*
.
KEY:
X@
= Audio mute setting 0 = Unmute the contact input channel. (Selects 0 for
X1*
.)
1 = Mute the contact input channel.
X1*
= Video mute setting 0 = Always unmuted (default), 1 = Off when muted, 2 = Blink when muted
